Scotch Brite with Oscillator

LEBON Scotch Brite with Oscillator is designed for producing a soft, uniform and refined Scotch Brite / SB matte finish on stainless steel sheets and plates. The oscillating system allows the Scotch Brite roller or finishing head to move left and right during operation, helping reduce fixed roller marks, improve full-width consistency and create a smoother decorative surface.

Product Details

Product Overview

The Scotch Brite with Oscillator Machine uses non-woven abrasive rollers together with controlled oscillation movement to achieve a more even and natural matte satin texture. Compared with a standard SB grinding machine, the oscillator design helps avoid repeated straight marks and improves surface uniformity across the sheet width.

With stable sheet feeding, adjustable roller pressure, variable conveyor speed and controlled oscillation, the machine is suitable for high-quality decorative stainless steel surface finishing. It can also be equipped with dust collection, cleaning, drying and optional protective film laminating systems according to customer requirements.

Key Features

Produces soft, uniform and matte Scotch Brite / SB finish
Oscillator system reduces fixed roller marks and repeated lines
Non-woven abrasive roller system for fine satin texture
Adjustable roller pressure for different sheet thicknesses
Variable conveyor speed for flexible surface effect control
Oscillation movement improves full-width surface consistency
Stable feeding system for smooth and even surface processing
Dry or wet processing options available
Dust collection system available for dry operation
Cleaning and drying section can be added if required
Optional protective film laminating after finishing
PLC and inverter control system for easy operation
Customizable working width, thickness range and roller configuration

Working Process

1. Material Feeding

The stainless steel sheet or plate is fed into the machine through the conveyor system. Stable feeding keeps the material flat and ensures consistent surface finishing.

2. Surface Pre-Treatment

Before Scotch Brite finishing, the surface can be cleaned or lightly pre-ground to remove dust, oil stains, minor scratches and surface defects.

3. Scotch Brite Roller Finishing

The non-woven Scotch Brite roller contacts the stainless steel surface and creates a soft, uniform and matte satin texture.

4. Oscillation Movement

During finishing, the oscillator system moves the roller or grinding head left and right. This helps reduce fixed roller marks, repeated straight lines and uneven surface patterns.

5. Pressure and Speed Adjustment

Roller pressure, conveyor speed and oscillation frequency can be adjusted according to material thickness, surface condition and required SB finish effect.

6. Dust Collection or Wet Cooling

For dry processing, the dust collection system removes grinding dust and abrasive particles. For wet processing, coolant or grinding liquid helps reduce heat and improve surface smoothness.

7. Surface Cleaning

After finishing, the surface is cleaned to remove dust, abrasive residue, metal particles and surface contamination.

8. Protective Film Laminating

If required, protective film is applied to the finished Scotch Brite surface to prevent scratches during handling, cutting, transportation and further processing.
