Product overview

The LEBON Titanium Surface Polishing Brushing Machine is designed for high-quality grinding, polishing and brushing of titanium sheets, plates and metal surfaces. It helps improve surface smoothness, remove minor defects and create a clean, uniform decorative or functional finish according to customer requirements.

The machine uses abrasive belt grinding, brushing and polishing technology to process titanium materials with stable surface contact and controlled finishing performance. It can be configured for different surface effects, such as satin brushing, fine polishing, hairline texture or pre-treatment before coating and further processing.

With a heavy-duty structure, adjustable grinding pressure, variable feeding speed, stable belt tracking and optional cleaning, drying and protective film laminating systems, the machine provides efficient and consistent titanium surface finishing. It is suitable for titanium panels, aerospace components, medical equipment parts, chemical industry plates, architectural decoration and premium metal products.

Key features

• Produces smooth, uniform polished and brushed titanium surfaces

• Suitable for titanium sheets, plates and flat metal surfaces

• Heavy-duty machine frame for stable and precise operation

• High-speed abrasive belt grinding and brushing system

• Adjustable grinding pressure for different titanium thicknesses

• Variable conveyor speed for flexible surface texture control

• Stable belt tracking system to prevent abrasive belt deviation

• Wet or dry processing options available

• Cooling system helps reduce heat and prevent surface discoloration

• Dust collection system available for dry polishing and brushing

• Cleaning and drying unit for a clean finished surface

• Optional protective film laminating after surface finishing

• PLC and inverter control system for easy operation

• Customizable working width, thickness range and machine layout

• Suitable for aerospace, medical, chemical, architectural and premium metal applications

working progress

Feeding Section

The titanium sheet or plate is fed into the machine through the conveyor system. Stable feeding ensures smooth movement and helps keep the surface finishing direction consistent.

Surface Grinding Section

High-speed abrasive belts grind the titanium surface to remove minor scratches, oxide layers and surface defects. This step improves surface flatness and prepares the material for brushing or polishing.

Brushing Section

The brushing unit creates a uniform satin, straight-line or hairline texture on the titanium surface. Belt grit, grinding pressure and feeding speed can be adjusted according to the required finish.

Polishing Section

The polishing section further improves surface smoothness and appearance. It helps achieve a clean, refined and high-quality titanium surface for decorative or industrial applications.

Cooling or Dust Control Section

For wet processing, coolant or grinding liquid helps reduce heat and prevent surface discoloration. For dry processing, a dust collection system can be used to remove titanium dust and keep the workshop cleaner.

Cleaning and Drying Section

After grinding, brushing or polishing, the titanium surface is cleaned to remove dust, oil, grinding residue and metal particles. The drying unit keeps the finished surface clean and ready for further processing.

Film Laminating Section

If required, a protective film is applied to the finished titanium surface to prevent scratches during handling, transportation or further production.

Finished Titanium Surface

The final titanium surface is smooth, uniform and high-quality, suitable for aerospace components, medical equipment parts, chemical plates, architectural decoration and premium metal products.

Technical specification

Applicable Material:
Titanium sheets, titanium plates and flat titanium metal surfaces

Surface Finish:
Satin brushing, fine polishing, hairline finish, customized surface texture

Material Thickness:
0.5–3 mm; customizable according to customer requirements

Working Width:
1000 mm, 1250 mm, 1550 mm; wider models can be customized

Processing Speed:
Adjustable according to material condition and required surface finish

Grinding Method:
High-speed abrasive belt grinding, brushing and polishing

Abrasive Belt Grit:
Selected according to required surface effect, from coarse grinding to fine brushing or polishing

Machine Type:
Automatic titanium surface polishing and brushing machine

Feeding System:
Stable conveyor feeding system with adjustable speed control

Pressure Control:
Adjustable grinding and brushing pressure for different titanium thicknesses and surface requirements

Cooling System:
Wet processing system available to reduce heat and prevent surface discoloration

Dust Collection System:
Available for dry polishing and brushing applications

Cleaning System:
Optional cleaning and drying unit to remove dust, oil, grinding residue and moisture

Laminating System:
Optional protective film laminating system after surface finishing

Control System:
PLC and inverter control system for easy operation and stable speed adjustment

Machine Structure:
Heavy-duty frame design for stable operation and reduced vibration

Customization Options:
Working width, thickness range, number of grinding heads, wet/dry process, electrical brand and machine layout

Application:
Titanium panels, aerospace components, medical equipment parts, chemical industry plates, architectural decoration and premium metal surface finishing

Apllications

• Titanium decorative panels

• Aerospace titanium components

• Medical equipment parts

• Chemical industry titanium plates

• Titanium heat exchanger plates

• Architectural decoration panels

• Premium metal interior panels

• Automotive titanium parts

• Marine industry components

• Electronic product shells

• Titanium furniture and design products

• Industrial titanium sheets and plates

• Pre-treatment before coating or surface treatment

• High-end metal surface finishing applications

Why choose Lebon

LEBON Titanium Surface Polishing Brushing Machine is designed for stable and precise finishing of titanium sheets, plates and flat metal surfaces. With strong experience in metal surface grinding, brushing and polishing equipment, LEBON helps customers achieve smooth, uniform and high-quality titanium surface results for industrial and premium applications.

The machine can be customized according to titanium thickness, working width, surface finish requirement and production capacity. With adjustable grinding pressure, stable feeding, wet or dry processing options, cooling system, dust collection, cleaning, drying and optional film laminating, LEBON provides a complete titanium surface finishing solution from machine design to installation, training and after-sales support.
